All Stainless Steel- Pressure Gauges with Bourdon Tube 0…100 bar
Código Interno: PRO38496
Actualizado: 2022-02-16
All Stainless Steel- Pressure Gauges with Bourdon TubeBrand: Kobold (Alemania)
Model: MAN-RF76-C2 + DRM-600 N15 + DF1
[MAN-RF76]:
Accuracy class 1,0
Diameter 100 mm
Housing st. st., filled*
Connection St.St.
Process Connection G 1/2 male
Max. medium temperature 80 °C**
[C2]: Indication range, 0...100 bar
**********************************************************************************
Include:
Diaphragm seals
Model: DRM 600 N15
Pressure range:
Connection: 1/2 NPT m.
Min: 0-100 Bar
Max: 0-1000 Bar
**********************************************************************************
Assembling together with pressure gauges
Model: DF1
Direct mounting
Assembly design, Glycerin oil
Max. op. temp. °C -10 to +80
**********************************************************************************
Datasheet: http://www.kobold.com/uploads/files/p1gb_man-r-chem.pdf
Diaphragm-All St. St. – G 1/2 male
Código Interno: PRO38826
Actualizado: 2022-02-16
Diaphragm-All St. St.Brand: Kobold (Alemania)
Model: MAN-PF76-B6
[MAN-PF76]:
Accuracy class 1.6
Housing diameter 100 mm
Housing st. st., filled*
Movement St.St
Connection Bottom, st.st., 10 mm borehole
Process Connection G 1/2 male
Max. medium temperature 80 °C
Flange connection, 1\" ANSI B 16.5, 150 Lbs
PTFE coating
[B6]: Indication range, 0-6Bar
**************************************************************************
Datasheet: http://www.kobold.com/uploads/files/p1gb_man-p.pdf
All Stainless Steel- Pressure Gauges with Bourdon Tube 0…100 bar
Código Interno: PRO39593
Actualizado: 2022-02-16
All Stainless Steel- Pressure Gauges with Bourdon TubeBrand: Kobold (Alemania)
Model: MAN-RF76-C2 + DRM-601 R40 + LS2
[MAN-RF76]:
Connection at bottom
Accuracy class, 1,0
Diameter, 100 mm
Housing st. st., filled
Connection St.St.
Process Connection G 1/2 male
Max. medium temperature 80 °C
[C2]: Indication range, 0...100 bar
Include:
Diaphragm seals
[DRM-601 R40]:
Threaded diaphragm
Material: stainless steel with fixed thread
Pressure range:
Min: 0-6 Bar
Max: 0-600 Bar
Temperature Range, -40°C a 200°C
Process connection, G 1 ½” male
Capillary
[LS2]: stainless steel 1.4571, Length 1.0 m
