Bimetallic Thermometers, AISI 316, ranges 0-200C

Código Interno: PRO46707

Bimetallic Thermometers
Brand: Kobold – Alemania
Model: TBE-2-3-C20-9A-8-C40-P00-R10-C01
[TBE-2]:
Housing material st.st.
Accuracy (DIN 16203) class 1
Connection to bottom
Probe st.st.
Process connection, AISI 316 St. St.
Welding, AISI 304 St. St. TIG
Case, AISI 304 St. St.
Ring, AISI 304 St. St. bayonet lock
Min. order quantity 5 pieces per order
[3] Diameter, 150mm
[C20] Measuring Range, Scale °C, ranges 0-200°C
bulb length (196 mm),
[9A] Probe type/Process connection,
sliding male and swivel nut 1/2 NPT
[8] Bulb diameter/-length, 8 mm
[C40] Case and ring stainless steel AISI 316
[P00] Suitable for glycerine filling IP 67
[R10] Options, Glycerine filling (max. 160 °C) IP 67
[C01] Options, Calibration report
