Conductive Suspended Electrodes

Código Interno: PRO47214

Conductive Suspended Electrodes
Model: NEH-L-HVF3-4420mm+NE-304-1
Brand: Kobold
[NEH]:
Number of electrodes 2..6
Connection G 1 1/2
max. length of electrodes 10 m, PTFE
Protection IP 65
[L]: Connection housing, Aluminium
[HVF3]: Material / cable / connect./ number of electr., Hastelloy / PTFE / PTFE / 3
L1= 120 +24 mm
L2= 4370 + 24 mm
L0= 4420 + 24 mm

Elektrode Relay
Brand: Kobold (Alemania)
Model: NE-304-1
[NE-304]:
Input, conductive electrodes
Limit switch or min/max monitoring, 2
Output relay, 2 SPDT
Contact rating, 250 VAC / 5 A / 600 VA
Sensitivity of response, 0-50 kOhm
Power required, 4 VA
Protection (housing/Connector), IP 40/IP 20
[1]: Power supply, 110 VAC
