Flujometro Electromagnetico EPS

Código Interno: PRO46669

EPS Electromagnetic Flow Meter
Brand: Heinrichs (Alemania)
Model: EPS-A-7050-N-N-0-2-0+UFM2-C-1-1-F-0BH-2
[EPS-A] Sensor
Material Lining Ceramics, Standard 2x Measuring Electrodes
Process Temperature, -20°C…+150°C
[7050] Process connection,  DN80 Tri-Clamp-Connection
Material Lining / Electrodes / Sealing, Ceramics / Platinum
Max. measuring range (Water 20°C, 1 mPas), 170 m³/h
Installation length, 256 mm
[N] Material Process connection, HC22(2.4602)PTFE-gasket
[N] Material electrodes, Platinum / Iridium
[0] Earthing electrode, w/o
[2] Transmitter mounting,  Remote Transmitter
Protection class, sensor IP 67 terminal conn.box via M 20 x 1,5
cable > 10m add. term.conn.box on transmitter
[0] Certificates, w/o

[UMF2] Transmitter
[C] Mounting, Integrated transmitter IP 67 standard
Connection to sensor, Incl 2,5 m cable, c/w pipe-/wall mounting bracke
Thread – electrical connection,
cable > 10m add. term.conn.box on transmitter  ½\» NPT (f)
[1] Display and control unit, integrated
[1] Power supply, 230V AC (+10%, -15%), 50/60Hz
[F] Output Signal:
current output: current output: 1x 0/4-20 mA
pulse output: passive Um=24 VDC
status output: passive Um=24 VDC
[0BH] Design, Heinrichs
[2] Longer cable, 10 m ;  breakout cable
